Ground-Breaking Technology

Clearaudio’s vision for the concept: Design an elegantly styled turntable package featuring a level of ground-breaking technology usually only found in high-end turntables, combining plug-and-play simplicity with outstanding sound quality and affordability.

Contemporary and Sophisticated

The concept achieves these highest of requirements, realising the Clearaudio vision. Beneath the sleek, contemporary exterior is a level of technical sophistication unique to Clearaudio. The concept‘s body is carefully crafted from medium-density wood fibre (or, optionally, pressure-formed solid wood) with a selection of smart made-to-match surface finishes. The body’s upper layer incorporates a special high-tech plastic compound designed to minimise unwanted resonance.

Engineering Prowess

The DC motor is fed by an external voltage-stabilised power supply and is completely decoupled from the chassis, isolating the record from any mechanical interference The concept tonearm features a magnetic bearing that is friction-free for extremely low distortion and superb performance. The package is completed with the high-quality Clearaudio concept MM or Clearaudio concept MC cartridge (toneam and/or cartridge upgrade possible).

Construction details:

Resonance-optimised turntable; chassis comprises medium-density wood fibre (silver / black) or pressure-formed solid wood (wood / dark wood); upper layer incorporates high-tech plastic compound.

Speed options:

33 ⅓, 45, 78rpm

Drive unit:

Decoupled and resonance damped 12V DC motor, flat belt-drive and plug-in power supply unit designed for worldwide use with all networks and power frequencies.

Bearing:

Polished and tempered steel spindle in a sintered bronze housing, running on a teflon thrust-pad.

Platter:

30mm / 1.18 inch main platter, made out of synthetic material with high-density and excellent dimension / precision CNC machined surface aluminium sub platter

Speed accuracy (measured):

± 0.05%

Power consumption:

Max. consumption: 2.5 watts
Consumption in operation: 0.5 watts
Off mode: 0.0 watts

Total weight:

Approx. 7.5kg (incl. tonearm and cartridge)

Dimensions (W/D/H):

Approx. 420 × 350 × 125mm (with tonearm)

Manufacturer’s warranty:

2 years Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
