Overview
Derived from the Angel-4, the Angel-4i has an upgraded 3-island power supply as used in the Angel-6 reference amplifier for even more transparency.
It uses our highly linear, low-feedback power amplifier design to deliver our renowned relaxed, open and transparent delivery of the musical performance.
We extend our low-feedback philosophy to the power supplies. The low-feedback amplifier is fed with incredibly pure, high current DC rails from low-feedback regulators.
The heavy machined casing uses different panel thicknesses to damp each other out and avoid vibration reaching the amplifier components.
The preamplifier uses the passive section from the Angel-Pre, with an ALPS ‘Blue Beauty’ potentiometer for the best sound with the convenience of a motorised volume control from the remote.
Speaking of the remote, it’s our lovely, machined from billet, tactile and practical remote control as used in the Angel-Pre.
The highly linear output stage uses 4 ring-emitter transistors to share the current load and remain linear, even when supplying large currents to keep a grip on the speakers.
The Angel-4i combines the world of pure low-feedback with the high output currents needed to deliver the whole authentic musical performance. It delivers musicality and subtlety along with power, scale and dynamics. It delivers Music!
Specifications
Output Power
75W RMS per channel into 8 ohms
150W RMS per channel into 4 ohms
Distortion
( with typical loudspeaker load )
THD: < 0.01%
IMD: < 0.01%
Loudspeaker Outputs
Nominal: 4 ohm to 16 ohm
Connections: Wired, Spade or 4mm plug
Inputs
RCA (phono) inputs:
1V rms for full output
Input Impedance 20k ohm
Frequency Response
5Hz to 50kHz +/- 1dB
Protections
Short Circuit or Overload: +/-15A max
Overtemperature: +55C
Undertemperature: +5C
Measurements
Amplifier dimensions:
Width 430mm x Depth 360mm x Height 120mm
Weight 16kg
Packaged dimensions:
Width 490mm x Depth 420mm x Height 170mm
Weight 18kg
Mains Power
IEC inlet cable for 230V AC 50Hz mains
Optional 115V AC 60Hz version available
Power Consumption:
Maximum 650VA
Idle 50VA
Standby < 0.5W
